- Small diameter hub can be fitted.
- Centering function is available.
- It has a hub stationary on the axis when assembled. |
|
| |
 |
- Surface roughness : Rt max16㎛
- Processing tolerance(Max) - Shaft : h8, Hub : H8 |
|
| |
 |
| - Pulley with small hub outside diameter | sprocket | gear | etc. |
|
|
|
|
| |
|
|
