- MAS is available for the shaft with a narrow diameter
- Type of rust protection as plated body and bolt
- Centering function is available.
- Decision on position is free.
- It has a shaft on the hub unmovable when assembled.
- Safe and precise fitting system




- Surface roughness : Rt max16㎛
- Processing tolerance(Max) - Shaft : h7, Hub : H7

- Gear | pulley | sprocket | cam, etc
